BLDC Motor Drive
TULPAR 275
4Q BLDC/PMSM/ACIM motor drive. 75 A rated, 120 A peak; for industrial platforms.
75A Rated Current
120A Peak Current
12–48V Voltage
4Q Topology
This drive is for BLDC / PMSM / ACIM motors only.
Key Features
4Q Regenerative
4-quadrant topology — recovers energy while decelerating, drives in every direction.
FOC / Six-Step
Field-oriented or six-step control depending on motor structure; high efficiency.
CANopen / Modbus
Modbus RTU and CANopen protocols — easy integration with PLCs and comms-based devices.
Feedback
Quadrature encoder, HALL and resolver support; differential or single-ended input.
STO Safety
Safe Torque Off for compliance with machine safety standards (on supported models).
Industrial Range
Brake output, industrial temperature range and multi-layer protection.
USB / RS232 / RS485
Wide connectivity with USB, RS232, CANBus and RS485 interfaces.
Made in Türkiye
Designed and manufactured in Kayseri. Engineering support from the same team.
Technical Specifications
ProtocolModbus and CANopen
InterfaceUSB / RS232 / CANBus / RS485
Operating Voltage12–48V DC
Rated Current (RMS)75 A
Peak Current (RMS)120 A
Matching MotorsBLDC / PMSM / ACIM
Digital Inputs5
Analog Inputs2
Digital Outputs2
FeedbackEncoder and HALL / Resolver (Optional)
Brake Output1
Temperature Range-10 °C / +40 °C
STO (Safe Torque Off)Yes (Isolated)
Topology4 Quadrant (4Q)
Documents
Other models in this series
Let's find the right drive for your project, together .
Share your application requirements and our engineering team will propose the best fit.
